Trench bridge w 1.09m l 7.21m h 1m

Trench bridge w 1.09m l 7.21m h 1m

Item no. 680050000

Safe traffic routes to and on the construction site

Ringlock trench bridges allow safe passage over hazardous areas on traffic routes, such as construction pits, watercourses or trenches. Ringlock can be flexibly adapted in width and length to the respective project requirements. In combination with construction stair towers, even greater differences in height can be safely overcome. Multi-span trench bridges are securely assembled on the ground in advance and then lifted into place by crane.

More information

The package consists of the following products

  • Starter base collar Item no. 301270000 Starter base collar 4 pcs.
  • Base jack 60cm Item no. 306010600 Base jack 60cm 8 pcs.
  • Jack retainer for lifting SW22 EU Item no. 306110004 Jack retainer for lifting SW22 EU 4 pcs.
  • Standard 1.00m crimped spigot Item no. 301011000 Standard 1.00m crimped spigot 4 pcs.
  • Standard 2.50m crimped spigot Item no. 301012500 Standard 2.50m crimped spigot 4 pcs.
  • Ledger 1.09m Item no. 301031095 Ledger 1.09m 6 pcs.
  • Ledger 2.07m Item no. 301032075 Ledger 2.07m 8 pcs.
  • Ledger 2.57m Item no. 301032575 Ledger 2.57m 12 pcs.
  • Bay brace 200/207cm Item no. 301062075 Bay brace 200/207cm 2 pcs.
  • Bay brace 200/257cm Item no. 301062575 Bay brace 200/257cm 4 pcs.
  • Steel plank 32/207cm Item no. 308032075 Steel plank 32/207cm 3 pcs.
  • Steel plank 32/257cm Item no. 308032575 Steel plank 32/257cm 6 pcs.
  • Steel toeboard yellow 2.07m Item no. 308402075 Steel toeboard yellow 2.07m 2 pcs.
  • Steel toeboard yellow 2.57m Item no. 308402575 Steel toeboard yellow 2.57m 4 pcs.
  • Scaffold tube 48.3mm 2.50m Item no. 682017000 Scaffold tube 48.3mm 2.50m 1 pc.
  • Swivel coupler 48mm Item no. 582560000 Swivel coupler 48mm 2 pcs.

Additional information

Product details

Safe traffic routes to and on the construction site

Ringlock trench bridges allow safe passage over hazardous areas on traffic routes, such as construction pits, watercourses or trenches. Ringlock can be flexibly adapted in width and length to the respective project requirements. In combination with construction stair towers, even greater differences in height can be safely overcome. Multi-span trench bridges are securely assembled on the ground in advance and then lifted into place by crane.

For larger spans (> 9.21 m) or extreme loads (> load class 3), temporary bridges from the Ringlock modular system offer the optimal solution.

Technical details

Weight / piece 603.19 kg
Packaged quantity 1 pc.
