Product Information
Dimensionally stable solid-web beam with multi-ply web and PUR beam-end reinforcement. (Approval n° Z-9.1-920)
With its low weight of just 5 kg/lin. m, the XT20 beam ensures ergonomic working. The proven height of 20 cm is ideal for use with existing accessories. The top beam end reinforcement offers reliable protection against splintering and moisture.
Product features:
- Extra load-bearing timber formwork beam in the proven construction height of 20 cm
- Can be used in beam-floor and beam-wall formwork systems
- Top-beam-end reinforcement as reliable protection against splintering and moisture
- Support bar made of high-quality plywood with grey bar coating
- Beams marked in 50-cm increment-grid
- 2 system holes at each beam end
- Notch for chalk line
- Labelling on belt width and bar; Optional: Customising possible
- Officially approved by the DIBt (Approval: Z-9.01-920)
Technical Data:
- Moment(M): 7,0 kNm
- Shear force (Q): 15,0 kN (16,5 kN)*
- Rigidity (EI): 585 kNm²
- Weight: 5,0 kg/lin. m
* According to approval Z-9.1-920, the permissible shear force may be assumed to be 16.5 kN if the permissible support force of 30 kN is complied with.
